1208 Pallet Sleeve Container
This foldable sleeve pack is robust but lightweight, offering unparalleled protection for your goods. It comes equipped with four pallet/sleeve locks that ensure a secure fit and two conveniently placed handles for easy handling and transportation.
- Overview
- Recommended Products
POLYFAVO pallet containers: Large Collapsible Pallet Boxes and Sleeve Solutions
POLYFAVO foldable large containers, also referred to as FLCs, Pallet Boxes, or Sleeve Packs, are designed to enhance your logistics operations. These durable and eco-friendly containers feature a pallet base, a collapsible sleeve, and a lid. They are perfect for loads that cannot be palletized, providing high folding efficiency, optimizing your reverse logistics, and saving floor space while ensuring durability. POLYFAVO foldable large containers boost logistics efficiency, lower costs, and promote sustainability, making them an essential asset for contemporary supply chain management.They are the key to a Lean and Streamlined Supply Chain.
These exceptionally durable pallet boxes and sleeve packs are built using three primary components:
①A Thermoformed HDPE Lid
The Thermoformed HDPE Lid has a dual function: it offers superior protection for your contents and enables the secure stacking of multiple containers. This ensures the safety of your items during transport and storage, while also maximizing space efficiency.
②An Extruded Polypropylene Sleeve
The extruded Polypropylene Sleeve preserves the container's structural integrity, securely holding items without any deformation, bulging, or tearing. Moreover, the sleeve can be folded flat for the reverse logistics, optimizing space.
We can provide Single Piece Pallet Sleeves and Multi-part Pallet Sleeves.
Single-piece pallet sleeves offer maximum load capacity and superior handling features. Their custom design ensures sleeve pack efficiency, while the custom and easy-folding systems enable optimal volume reduction. This can result in up to 80% savings in return transport volume. The Single Piece Pallet Sleeves can be folded into M shape, Z shape and one shape. The load door is an important feature for loading and unloading large carriers with single piece pallet sleeves.
Multi-part pallet sleeves are ideal for effortless loading and unloading of products. Key features include streamlined handling, process-oriented configurations, and volume reductions of up to 80%.
③A Thermoformed HDPE Pallet Base
The thermoformed HDPE Pallet serves as the foundation of the container and are compatible with AGVs and traditional forklifts. The pallets and lids with high framed rim can ensure product protection and safe return stacking.
Key benefits include:
①Space Optimization:
POLYFAVO pallet containers can be effortlessly folded when not in use, which obtains optimal return and stacking. Our designers customize sleeve packs to match specific product dimensions and needs, offering options like Z or M folding styles and openings placed on the narrow side rather than the long side.
②Cost Saving:
The average container weight of 24 kg is considerably lighter than packaging made from steel or wood. This leads to reduced transport costs and more efficient vehicle payload utilization. Additionally, they take up less space when empty since they are collapsible which leads to lower shipping expenses and a more efficient supply chain.
③Ease of handling:
POLYFAVO foldable containers are designed for easy handling, whether manually or with machinery. This enhances loading and unloading efficiency, reducing labor costs and boosting overall operational productivity. Foldable PP containers meet international shipping standards, making them ideal for global trade and minimizing the need to transfer goods between different container types at various points of the supply chain.
④Storage Efficiency:
In warehouses, POLYFAVO reusable bulk boxes occupy less storage space, allowing for improved organization and more efficient use of warehouse space.
⑤Durability:
POLYFAVO collapsible bulk containers offer an ideal combination of strength and ease of handling. They ensure your goods are securely protected throughout the supply chain while maintaining operational efficiency. Their excellent rigidity is provided by our boxes, effectively shielding your goods from moisture, dust, and shocks.
⑥Customization:
Our expert team will create the ideal sleeve packs tailored to your specific requirements, whether you need an opening on the narrow side or the long side. This prevents the strenuous task of loading and unloading heavy products for your operators with a custom large container configuration.
POLYFAVO foldable boxes provide dependable options for transporting and storing various irregularly shaped and hard-to-palletize items, packages, and boxes. They are not only durable but also fully customizable to meet your specific requirements. we are able to design containers to your requested length, width, and height. Whether you're transporting large machines, bulk products, or delicate items, our custom-made polypropylene pallet boxes ensure a perfect fit and provide ultimate peace of mind.
Product parameter
Style |
Foldable Sleeve Pack |
Brand |
POLYFAVO |
Material |
100% Recycled HDPE Base (Lid and Pallet) , and 100% virgin PP sleeve - Overall 67% recycled |
Recycled Plastic |
No |
Type |
Solid |
Colour |
Black/ Grey |
Size |
1200mm x 800mm |
Height (mm) |
1000 |
Weight (kg) |
24.2 |
External Dimensions (mm) |
1200mm x 800mm x 1000mm |
Internal Dimensions (mm) |
1150mm x 750mm x 822mm |
Folded Height (mm) |
258 |
Pallet Stack Quantity |
11 |
Max Load per Box |
500kg (Stacked 2:1) |
Max stack load (kg) |
1000 |
Foldable |
Yes |
Volume (l) |
710 |
Static (kg) |
1000 |
Dynamic (kg) |
500 |
Rackable |
No |
Can be printed with your branding |
Yes |
Printing |
On demand |
Trailer/Truck Quantity |
99 Full / 363 Folded |
Box Base |
On 9 feet |
Units per stack |
11 |
Truck Quantity |
363 |
Lid |
Included |
Optional features |
● Pallet/Sleeve locks (Pallet interlocks with lid to keep stacked containers stable.) ● Sliding tabs snap into place securing sleeve, pallet and lid. ● Handles |
Features |
● Thermoformed plastic 4-way entry pallet and lid. ● ①Closed base and slides with drop door and lid②Two handles ● The groove design of the lids ensures stable stacking and is not easy to fall off. ● Up to 80% less volume on the return cycle ● More than 70% lighter than traditional pallet cages ● 100% recyclable ● Stackable ● Environmentally friendly ● Nestable ● Foldable, high folding ratio ● 100% recyclable ● Does not absorb liquids and easy to clean ● Long life span: 3+ years ● Full water and dust protection ● Resistant to most oils and acids ● Suitable for intelligent logistics turnover ● Efficient! Pack, stack, ship, fold, return - repeat! ● Thermal insulation ● No deformation ● Non-toxic ● Odorless ● High toughness ● Moisture resistant ● Bend resistant ● Flame retardant ● UV radiation resistant ● Dirt resistant ● Corrosion resistant ● High impact resistant ● Chemical resistant ● Weather resistant ● Stand wear and tear ● Anti-aging ● Rot resistant ● Pest resistant ● Fungus resistant ● Break resistant ● Easily cleaned ● Easy to handle |
Accessories |
1 HDPE lid (Closed base and slides with drop door and lid) 1 PP sleeve 1 HDPE pallet 2 Belt handles 4 Belt locks 1 Label holder 2 Velcros 1 Loading door |
Application |
Storing or shipping bulk goods and outdoor equipment such as auto parts, furniture, machinery and electrical components. |
Packaging |
Fold and Wrap |
Place of Origin |
China |
FOB port |
Qingdao |
OTHER PALLET & LID SIZE
Blow Molding Type
Model |
Pallet Outer Diameter |
Pallet Inner Diameter |
Pallet Weight |
Lid Weight |
STACKING LAYER |
LOADING WEIGHT |
BM8060 |
800*600 |
740*540 |
7kg |
5kg |
1+2 |
300KGS |
BM1110 |
1100*1000 |
1050*950 |
10kg |
7.5kg |
1+2 |
300KGS |
BM1111 |
1100*1100 |
1055*1055 |
10kg |
8kg |
1+2 |
300KGS |
BM1198 |
1150*985 |
1100*935 |
10kg |
9kg |
1+2 |
300KGS |
BM1515 |
1150*1150 |
1105*1105 |
10.5kg |
8.5kg |
1+2 |
300KGS |
BM1280 |
1200*800 |
1140*740 |
10kg |
9kg |
1+2 |
300KGS |
BM1210 |
1200*1000 |
1140*940 |
11kg |
10kg |
1+2 |
300KGS |
BM1211 |
1220*1150 |
1170*1105 |
11kg |
9kg |
1+2 |
300KGS |
BM1210-3 |
1230*1030 |
1170*970 |
11.5kg |
8.5kg |
1+2 |
300KGS |
BM1311 |
1350*1140 |
1290*1080 |
14kg |
12kg |
1+2 |
300KGS |
BM1411 |
1470*1140 |
1410*1080 |
15kg |
13kg |
1+2 |
300KGS |
BM1611 |
1600*1140 |
1540*1085 |
20kg |
13kg |
1+2 |
300KGS |
BM1811 |
1840×1130 |
1540*1080 |
23kg |
12kg |
1+2 |
300KGS |
BM2011 |
2070*1150 |
2035*1115 |
30kg |
16kg |
1+2 |
300KGS |
Injection Type
Model |
Pallet Outer Size |
Pallet Inner Size |
FOLDING HEIGHT |
LOADING WEIGHT |
STACKING LAYERS |
REMARK |
ZS1210 |
1200*1000 |
1130*930 |
240 |
500 |
5 |
9 FEET/3 RUNNERS |
ZS1280 |
1200*800 |
1130*730 |
240 |
500 |
5 |
9 FEET/3 RUNNERS |
ZS1198 |
1140*980 |
1070*910 |
240 |
500 |
5 |
9 FEET/3 RUNNERS |
ZS1111 |
1140*1140 |
1070*1070 |
240 |
500 |
5 |
9 FEET/3 RUNNERS |
1.Lashing Belts and handle belts can be added | ||||||
2. 9 feets/3 runners are for options. | ||||||
3. Steel Tube can be added in pallet and lid for higher loading weight. | ||||||
